1. For Factory Production line test.
2. For Mobile phone ,computer repair, electrical appliance maintenance,Car DVD, car audio, etc.
3. For Product aging, electroplating,titanium oxide,electrolysis,such as resistors, jewelry,capacitors, relays, DC motors, LEDs, etc.
4. For Charge the battery (Include car battery).
5. For Laboratory, scientific research teaching,factory, maintenance power supply,school ,scientific research , production line use,etc.
6. For Security monitoring system, fire protection system, building automation system.
Model Name |
SPS-E305 |
SPS3010 |
SPS305S |
SPS3010S |
SPS605S |
SPS1203S |
SPPS305D |
SPPS3010D |
SPPS605D |
SPPS1203D |
SPPS2001D |
SPPS3001D |
Output Voltage |
0-30V |
0-30V |
0-30V |
0-30V |
0-60V |
0-120V |
0-30V |
0-30V |
0-60V |
0-120V |
0-200V |
0-300V |
Output Current |
0-5A |
0-10A |
0-5A |
0-10A |
0-5A |
0-3A |
0-5A |
0-10A |
0-5A |
0-3A |
0-1A |
0-1A |
Output Power |
150W |
300W |
150W |
300W |
300W |
360W |
150W |
300W |
300W |
360W |
200W |
300W |
Screen Display 1 |
LED Screen Display |
Color LCD Screen Display |
Screen Display 2 |
3-digit Digital Display,No Power Display |
4-digit Digital Display,Power Display |
Adjustment Method |
Double Knob Encoder Precise Adjustment |
4-knob potentiometer fine adjustment |
4-knob encoder for precise adjustment |
Single knob encoder for precise adjustment |
Output Switch Button |
No |
Yes |
USB Port |
No |
5V 2A for mobile phone repair and charging |
USB A Quick charging port. USB C Quick charging port. |
5V 2A for mobile phone repair and charging |
Memory Function |
No |
4 Storage Memory Function Buttons |
Input Voltage |
230V±10% 50Hz and 115V±10% 50Hz |
230V±10% 50Hz or 115V±10% 60Hz |
Working Temperature |
0℃-40℃;Relative Humidity:<80%RH |
Storage temperature |
-10℃-70℃;Relative Humidity:<70%RH |
Constant voltage State |
Voltage stability≤0.1%+3mV |
Low Voltage:0.2-0.3%+3mV |
Load stability: 0.5%±3mV |
Ripple noise ≤30mVrms |
0 to rated voltage continuously adjustable |
Constant Current State |
Current stability:0.2%+3mA |
Load stability: 0.2%±3mA |
Ripple noise ≤20mArms(Valid Value) |
Recovery time:≤500μS |
Temperature coefficient:≤100ppm/℃ |
0 to rated current continuously adjustable |
Display |
Display size:5.3cm*4.8cm |
Display accuracy:0.5%±2digits |
Display resolution voltage:0.1V |
Display resolution Current : 0.01A |
|
Display resolution power :0.001W |
Net weight |
0.69KG |
1.2Kg |
1.3kg |
Fuse standard |
3A |
3A(AC 220V inpute) ,5A (AC 110V inpute) |
Product color |
Black |
Product size |
Long18.5cm x Wide10cmx High 7.8cm |
Long 20cm x Wide8.5cm x High 15cm |
Long 22cm x Wide8.5cm x High 15cm |
Built-in cooling fan |
Automatically start at boot |
Smart turn on when temperature over 50℃ |
Q: Is it suitable for repairing mobile phones and laptops?
A: Yes.
Q: Does this power supply charge the battery of a 25V car?
A: You can charge a 25V battery, because the maximum voltage of the power supply can reach 30V (note！！the power supply Set up voltage must be greater than the battery voltage before it can charge it, otherwise it will kick back the power supply and damage the power supply!)
Q: Can it be used for electroplating and anodizing?
A: It can be electroplated and anodizing.
Q: When does the fan rotate?
A: When the internal temperature of the power supply is greater than 50℃, it will start automatically.
Q: When this power is turned off and on again, does it remember the last setting?
A: It is controlled by the adjustment knob, and as long as you don't move the adjustment knob, it will power on at the previous setting.
Q: Can an EU plug be configured for me?
A:we can configure four types of plugs for your region: EU,UK,AU,US.
1*Power supply
1*Power Adapter(EU/AU/UK/US optional)
2*output line(gift)
1*Instruction Book (English)
1*Package Box
1*Certificate of conformity
SPS-S Series (Upgraded Model):
1.LED screen, 4-digit display, charged power display.
2.4 knob encoder for fine adjustment, coarse adjustment + fine adjustment.
3. The USB-A fast charger port supports fast charging protocol.
4.The USB-C fast charger port supports fast charging protocol.
5. "OCP" overcurrent protection button. Press and hold for five seconds to set the current limit. If the output current exceeds the limit current, the output will be disconnected and "OCP" will be displayed.
6. "OVP" overvoltage protection button. Press and hold for five seconds to set the limit voltage value. If the output voltage exceeds the limit voltage, the output will be disconnected and "OVP" will be displayed.
7. The "OUTPUT" output switch button controls the opening/closing of current and voltage output.
8. With buzzer function. Turn and push the knobs and buttons and there will be sound. Press and hold "V-FINE" for 5 seconds to turn on/off the buzzer.
SPS-E305 (Mini Model):
1.LED display, 3-digit display, no power display.
2. Double knob encoder for precise adjustment.
3.Wide voltage, can be used in 110V and 220V at the same time (note: other models have single voltage input, please purchase according to the national input voltage)
4. There is no intelligent heat dissipation, and the cooling fan automatically starts when it is turned on.
SPS3010 (Ordinary Model):
1.LED screen, 4-digit display, with power display.
2.4 Knob potentiometer coarse adjustment + fine adjustment, adjustment depends on feel. Coarse adjustment adjusts the first two digits, and fine adjustment adjusts the last two digits.
3. USB 5V 2A output port, can charge mobile phones.
SPPS-D Series (Programming Model)：
1. Color LCD screen, 4-digit display, with power display.
2. Single-knob encoder for precise adjustment.
3. USB 5V 2A output port, can charge mobile phones.
4.4 groups of storage memory functions (M1/M2/M3/M4), you can set commonly used current and voltage with one click.
5. "LOCK" lock screen button, lock the buttons and knobs with one click to avoid electrical damage caused by accidental touch.
6. "V/A" current and voltage switching button, using the adjustment knob, you can accurately adjust the current/voltage.
7. "On/Off" output switch button to control current and voltage output/on.
